This is a simple GridView App with Drawer, App bar, and Tabbar. A Flutter staggered grid view which supports multiple columns with rows of varying sizes.
A material design app bar.
An app bar consists of a toolbar and potentially other widgets, such as a TabBar and a FlexibleSpaceBar. App bars typically expose one or more common actions with IconButtons which are optionally followed by a PopupMenuButton for less common operations (sometimes called the "overflow menu").
App bars are typically used in the Scaffold.appBar property, which places the app bar as a fixed-height widget at the top of the screen. For a scrollable app bar, see SliverAppBar, which embeds an AppBar in a sliver for use in a CustomScrollView.
import 'package:flutter/material.dart';
import 'package:flutter_staggered_grid_view/flutter_staggered_grid_view.dart';
void main() {
runApp(MyApp());
}
class MyApp extends StatelessWidget {
// This widget is the root of your application.
@override
Widget build(BuildContext context) {
return MaterialApp(
title: 'Flutter Demo',
theme: ThemeData(
primarySwatch: Colors.blue,
visualDensity: VisualDensity.adaptivePlatformDensity,
),
home: HomePage(),
);
}
}
class HomePage extends StatelessWidget {
@override
Widget build(BuildContext context) {
return DefaultTabController(
length: 2,
child: Scaffold(
drawer: Drawer(
child: ListView(
padding: EdgeInsets.zero,
children: <Widget>[
DrawerHeader(
child: Text('Drawer Header'),
decoration: BoxDecoration(
color: Colors.blue,
),
),
ListTile(
title: Text('Item 1'),
onTap: () {
Navigator.pop(context);
},
),
ListTile(
title: Text('Item 2'),
onTap: () {
Navigator.pop(context);
},
),
],
),
),
backgroundColor: Color(0xffE5E5E5),
appBar: AppBar(
bottom: TabBar(
tabs: [
Tab(
text: 'Home',
),
Tab(text: 'Favourites'),
],
),
backgroundColor: Colors.cyan,
actions: <Widget>[
IconButton(
splashColor: Colors.orange, // Splash colors onlongpressed
tooltip: 'search here',
icon: Icon(
Icons.search,
color: Colors.white,
),
onPressed: () {},
),
],
centerTitle: true,
title: Text(
"GridViewSearch",
style: TextStyle(
color: Colors.white,
fontWeight: FontWeight.bold,
),
),
),
body: HelpingApp(),
),
);
}
}
class HelpingApp extends StatefulWidget { HelpingApp({ Key key, }) : super(key: key); @override _HelpingAppState createState() => _HelpingAppState(); } class _HelpingAppState extends State<HelpingApp> { @override Widget build(BuildContext context) { return TabBarView(children: [ Container( color: Colors.deepPurple, child: StaggeredGridView.count( padding: EdgeInsets.all(12.0), scrollDirection: Axis.vertical, crossAxisCount: 3, crossAxisSpacing: 12.0, mainAxisSpacing: 12.0, children: <Widget>[ Tooltip( message: 'facebook', child: Material( color: Colors.tealAccent, elevation: 14.0, borderRadius: BorderRadius.circular(10.0), shadowColor: Color(0x802196F3), child: FlatButton( shape: new RoundedRectangleBorder( borderRadius: new BorderRadius.only(topRight: Radius.circular(56)), ), onPressed: () { print('facebook clicked'); }, child: Column( children: <Widget>[ Container( child: Image( width: 200, height: 68, fit: BoxFit.contain, image: AssetImage( 'assets/f.jpg', ), ), ), Container( child: FittedBox( fit: BoxFit.contain, child: Text( 'FaceBook', style: TextStyle( fontSize: 11, fontWeight: FontWeight.bold, decorationThickness: 8, letterSpacing: 2, color: Colors.black, ), textAlign: TextAlign.center, ), ), ), ], ), ), ), ), Tooltip( message: 'Google', child: Material( color: Colors.tealAccent, elevation: 14.0, borderRadius: BorderRadius.circular(10.0), shadowColor: Color(0x802196F3), child: FlatButton( shape: new RoundedRectangleBorder( borderRadius: new BorderRadius.circular(10.0), ), onPressed: () {}, child: Column( children: <Widget>[ Container( margin: EdgeInsets.only(top: 8.0), child: Image( width: 200, height: 68, fit: BoxFit.contain, image: AssetImage( 'assets/g.jpg', ), ), ), Container( margin: EdgeInsets.only(top: 3.0), child: Text( 'Google', style: TextStyle( fontSize: 11, fontWeight: FontWeight.bold, decorationThickness: 8, letterSpacing: 2, color: Colors.black, ), textAlign: TextAlign.center, ), ), ], ), ), ), ), Tooltip( message: 'Microsoft', child: Material( color: Colors.tealAccent, elevation: 14.0, borderRadius: BorderRadius.circular(10.0), shadowColor: Color(0x802196F3), child: FlatButton( shape: new RoundedRectangleBorder( borderRadius: new BorderRadius.circular(10.0), ), onPressed: () {}, child: Column( children: <Widget>[ Container( margin: EdgeInsets.only(top: 8.0), child: Image( width: 200, height: 68, fit: BoxFit.contain, image: AssetImage( 'assets/m.jpg', ), ), ), Container( margin: EdgeInsets.only(top: 3.0), child: Text( 'Microsoft', style: TextStyle( fontSize: 11, fontWeight: FontWeight.bold, decorationThickness: 8, letterSpacing: 2, color: Colors.black, ), textAlign: TextAlign.center, ), ), ], ), ), ), ), Tooltip( message: 'GitHub', child: Material( color: Colors.tealAccent, elevation: 14.0, borderRadius: BorderRadius.circular(10.0), shadowColor: Color(0x802196F3), child: FlatButton( shape: new RoundedRectangleBorder( borderRadius: new BorderRadius.circular(10.0), ), onPressed: () {}, child: Column( children: <Widget>[ Container( margin: EdgeInsets.only(top: 8.0), child: Image( width: 200, height: 68, fit: BoxFit.contain, image: AssetImage( 'assets/git.png', ), ), ), Container( margin: EdgeInsets.only(top: 3.0), child: Text( 'GitHub', style: TextStyle( fontSize: 11, fontWeight: FontWeight.bold, decorationThickness: 8, letterSpacing: 2, color: Colors.black, ), textAlign: TextAlign.center, ), ), ], ), ), ), ), Tooltip( message: 'Guy', child: Material( color: Colors.tealAccent, elevation: 14.0, borderRadius: BorderRadius.circular(10.0), shadowColor: Color(0x802196F3), child: FlatButton( shape: new RoundedRectangleBorder( borderRadius: new BorderRadius.circular(10.0), ), onPressed: () {}, child: Column( children: <Widget>[ Container( margin: EdgeInsets.only(top: 8.0), child: Image( width: 200, height: 68, fit: BoxFit.contain, image: AssetImage( 'assets/guy.gif', ), ), ), Container( margin: EdgeInsets.only(top: 3.0), child: Text( 'Guy', style: TextStyle( fontSize: 11, fontWeight: FontWeight.bold, decorationThickness: 8, letterSpacing: 2, color: Colors.black, ), textAlign: TextAlign.center, ), ), ], ), ), ), ), ], staggeredTiles: [ StaggeredTile.extent(1, 100.0), StaggeredTile.extent(1, 100.0), StaggeredTile.extent(1, 100.0), StaggeredTile.extent(1, 100.0), StaggeredTile.extent(1, 100.0), ], ), ), Container( child: Center(child: Text('No Favourites are Added')), ) ]); } }
A beginner flutter Gridview complete app example.
